Sincola SH series industrial hose pump is a kind of peristaltic
pump, which is suitable for handing aggressive, high viscosity,
high density products, such as abrasive slurries, corrosice acids,
gaseous liquid, sand/cement mortar, etc. Also is used for dosing
pump with 1% repeat precision.
Peristaltic Hose Pump Features:
- Unique structure with no sealing element, no leakage, no
pollution;
- Advanced rolling technology adopted, no need of lubrication for
roller;
- High suction ability, self-cleaning ability, sucking materials in
two directions;
- Simple hose installation, simple operation, easy to assemble and
maintain, lower maintenance cost;
- Linear regulation of flow rate, limited measuring ability;
- No block when pumping fluid with high viscosity and foreign
substance contained;
- Long service life;
- High delivery lift and output pressure.
Technical Parameters:
| Model | SH100 Industrial Hose Pump |
| Output | 2000~28000 L/h |
| Rated pressure | 1.0 MPa |
| Rev. | 40~55 r/min |
| Hose length | 1900 mm |
| Max. particle dia. | 10 mm |
| Max. suction dist. | 5 m |
| Motor power | 7.5 KW |
| Reducer type | Gear reducer |
Note:
1. Driven power could be electric motor or diesel engine.
2. Various squeeze hoses are available for pumping different
materials.
3. Customized pump is available.
Hose Squeeze Pump Application:
1. Architecture: mortar, plaster, cement paste, soil slurry, silt
slurry, lime slurry, foamed concrete, architectural coating,
refractory, accelerator, waste water, sewage and so on.
2. Chemical: corrosive, acid, alkali, phosphate liquid, inorganic
materials, crystalline liquid, suspending liquid, emulsion, resin,
electroplate liquid, electrolyte solution, precipitate.
3. Oil industry: drilling fluid,crude oil.
4. Cosmetics industry: toothpaste, emulsion, hair conditioner, face
cream, facial oil.
5. Ceramic industry: ceramic germ plasma, slip glaze, glaze
materials.
6. Others: pharmaceutical liquid, radioactive liquid, textile
auxiliary, adhesion agent, glue, latex.
Company Introduction
Sincola has been engaged in the research and production of hose
pump for many years. With the experiences and special technology
SINCOLA won a quick development on the hose pump int the recent
years.
Today SINCOLA hose pumps are the very mature products wiwth
different kinds of types. The work pressure can reach 1.5Mpa and
the output can be 40 cubic meters/hour. SINCOLA pumps are widely
applied at home and abroad. Based on the excellent work principle,
SINCOLA hose pumps will have a more extensive application in the
next days.
If you need more informations, please contact with me.
