There is a specially made rubber hose with smooth inner surface and
high strength installed in the pump body. When a pair of roller
rotate and squeeze the hose, the rotation and squeezing force will
force the transported material flow in single direction and with no
back flow. After the material in hose is transported, the squeezed
hose will return to its normal shape by its elasticity and pressing
force of side rollers. During this procedure, the vacuum generated
will suck the material into hose cavity, and then, the sucked
material will be squeezed by coming rollers and discharged from the
output again. With the continuous rotation of roller, the material
is sucked and discharged continuously.
Peristaltic Hose Pump Features:
- Unique structure with no sealing element, no leakage, no
pollution;
- Advanced rolling technology adopted, no need of lubrication for
roller;
- High suction ability, self-cleaning ability, sucking materials in
two directions;
- Simple hose installation, simple operation, easy to assemble and
maintain, lower maintenance cost;
- Linear regulation of flow rate, limited measuring ability;
- No block when pumping fluid with high viscosity and foreign
substance contained;
- Long service life;
- High delivery lift and output pressure.
Technical Parameters:
| Model | KH76B Squeeze Hose Pump |
| Output | 18000~28000 L/h |
| Rated pressure | 1.0 MPa |
| Rev. | 40~55 r/min |
| Hose length | 1900 mm |
| Max. particle dia. | 6 mm |
| Max. suction dist. | 5 m |
| Motor power | 11.0/ 15.0 KW |
| Reducer type | Cycloidal reducer |
Note:
1. Driven power could be electric motor or diesel engine.
2. Various squeeze hoses are available for pumping different
materials.
3. Customized pump is available.
Hose Squeeze Pump Application:
1. Architecture: mortar,plaster,cement paste,soil slurry,silt
slurry,lime slurry,foamed concrete, architectural coating,
refractory,accelerator,ooze,waste water,sewage and so on.
2. Chemical: corrosive,acid,alkali,phosphate liquid,inorganic
materials,crystalline liquid,suspending
liquid,emulsion,resin,electroplate liquid,electrolyte
solution,precipitate.
3. Agriculture: phosphate fertilizer,compound fertilizers,thick
slurry, precipitated sludge.
4. Mining: gold pulp,tailings,thick pulp,filling
materials,underground drainage,adsorbent,slurry, mortar...
5. Paper industry: paper pulp, liquid sulfur.
6. Food and Beverage: oil, brew, milk, confiture, salad, syrup,
chocolate.
7. Oil industry: drilling fluid,crude oil.
Application:
Mining well project, hydropower engineering, highway (railway)
tunnel, subway engineering, bridge and slope maintenance, air-raid
shelter construction, municipal construction, environmental
greening project, blast-furnace refractories spraying, etc.
Company Introduction
Sincola has been engaged in the research and production of hose
pump for many years. With the experiences and special technology
SINCOLA won a quick development on the hose pump int the recent
years.
Today SINCOLA hose pumps are the very mature products wiwth
different kinds of types. The work pressure can reach 1.5Mpa and
the output can be 40 cubic meters/hour. SINCOLA pumps are widely
applied at home and abroad. Based on the excellent work principle,
SINCOLA hose pumps will have a more extensive application in the
next days.
If you need more informations, please contact with me.
