Widely Application Tunnel Working Equipment Wet Shotcrete Pump
Machine
Introduction
Wet Shotcrete Pump:
Used for pump and spraying concrete.
When pump, 15-20 cubic meter per hour, is one small concrete pump.
Contact with air compressor, also can be used for spraying
concrete.
The machine is suitable either for manual spraying or by means of a
robotic arm.
We have 20 years produce expericence with advanced technology,
rational structure, stable performance and long service life
shotcrete machine is widely used for concrete spraying operation in
the tunnel, culvert, subway, hydroelectric works, underground works
and high-methane laneway of coal mine.
Technical Parameters of Wet Concrete Shotcrete Pump:
| Model | Unit | SPB8I |
| Capacity | m3/h | 8 |
| Max. aggregate size | mm | 15 |
| Fineness modulus | / | ≥2.5 |
| Delivery pipe | mm | DN100/DN80 |
| Concrete slump | cm | 10~18 |
| Max. horizontally conveying dist. | m | 150 |
| Max. vertically conveying dist. | m | 80 |
| Main motor power | kw | 22 |
| Max. operating oil pressure | M pa | 19 |
| Max. output pressure | M pa | 8 |
| Feeding height | mm | 1100 |
| Dimensions (L×W×H) | mm | 2990×1200×1140 |
| Weight | kg | 1600 |
Application:
convey fine aggregate concrete and mortar for high buildings.
grout heat-insulated lightweight foamed cement, mortar floor
heating, and self leveling for ground architecture.
spray plain concrete and fiber concrete in engineering
construction.
convey and spray refractory and thermal insulation material.
spray afforestation soil in ecological environment construction.
pressure perfussion for foundation piles, back fill in over broken
tunnels, railway slope supporting, and disaster management.
Features of shotcrete concrete pump
SPB Full Hydraulic Mini Shotcrete Pump Machine
high efficiency: full hydraulic pumping technical, reliable
performance.
long spraying distance: 150m horizontally and 80m vertically.
continuously adjustable flux and accelerator adding volume.
low fitting consumption, long service life of wearing parts.
flexible movement, convenient operation and maintenance.
Shipping and packing:
Packing: Wooden case
Ship and air transport is allowed
About Us:
Zhengzhou Sincola Machinery Co., Ltd. is a high-technology, modern
enterprise established in 2001, professionally engaged in the
R&D and manufacturing of construction materials(concrete,
mortar,cement etc)pumping and spraying.
Our main products: concrete spraying machine,concrete pumping
machine, mortar spraying,plaster machine and mortar pump,hose pump,
wall rendering machine etc,widely used in railway, tunnel, highway,
housing construction support and other projects built facilities.
Products are sold well all over the country, and exported to
eastern Europe, Middle East, southeast Asia, central Asia, South
Asia, Africa, the Americas, Oceania more than 30 countries and
regions.
If you are interested in our products, please contact us with no
hesitation. We are sure any of your questions will get our prompt
attention& reply. And we are looking forward to your visit to our
factory. Welcome
After-sales Service Provided:
Video technical support, Field installation, commissioning and
training, Field maintenance and repair service, Free spare parts,
Online support
